ACE API Endpoints

ACE includes API endpoints for some of its most frequently used functions.

API Reference

ACE provides a REST API for programmatic access. The API server runs on localhost:5000 by default. An SSH tunnel is required to access the API from outside the host machine for security purposes.

Configuring Authentication for ACE

You should create a client certificate separately for ACE with all necessary privileges on tables, schemas, and databases that you want to use with ACE. This user should preferably be a superuser since ACE may need elevated privileges during diffs and repairs.

Each external user should have their own client certificate to use the API, typically with lower privileges. ACE will attempt to use SET ROLE to switch to the external user's role before performing any operations, thus ensuring that diffs and repairs happen with the external user's privileges.

You must also configure client-based certificate authentication before using the ACE API.

Please refer to Postgres documentation (opens in a new tab) for information about setting up server and client certificates. Please note that after creating your certificate, you must provide details in the following postgresql.conf parameters (opens in a new tab):

ssl = on
ssl_ca_file
ssl_cert_file
ssl_key_file

You should also enable cert authentication in the pg_hba.conf (opens in a new tab) file:

hostssl all all 192.168.0.0/16 cert

After configuring authentication for ACE, restart the Postgres server for the changes to be applied.

The table-diff API

Initiates a table diff operation.

Endpoint: GET /ace/table-diff

Request Body:

{
    "cluster_name": "my_cluster",        // required
    "table_name": "public.users",        // required
    "dbname": "mydb",                    // optional
    "block_rows": 10000,                 // optional, default: 10000
    "max_cpu_ratio": 0.8,                // optional, default: 0.6
    "output": "json",                    // optional, default: "json"
    "nodes": "all",                      // optional, default: "all"
    "batch_size": 50,                    // optional, default: 1
    "table_filter": "id < 1000",         // optional
    "quiet": false                       // optional, default: false
}

Parameters:

cluster_name (required): Name of the cluster
table_name (required): Fully qualified table name (schema.table)
dbname (optional): Database name
block_rows (optional): Number of rows per block (default: 10000)
max_cpu_ratio (optional): Maximum CPU usage ratio (default: 0.8)
output (optional): Output format ["json", "csv", "html"] (default: "json")
nodes (optional): Nodes to include ("all" or comma-separated list)
batch_size (optional): Batch size for processing (default: 50)
table_filter (optional): SQL WHERE clause to filter rows for comparison
quiet (optional): Suppress output (default: false)

Example Request:

curl -X POST "http://localhost:5000/ace/table-diff" \
  -H "Content-Type: application/json" \
  --cert /path/to/client.crt \
  --key /path/to/client.key \
  -d '{
    "cluster_name": "my_cluster",
    "table_name": "public.users",
    "output": "html"
  }'

Example Response:

{
    "task_id": "td_20240315_123456",
    "submitted_at": "2024-03-15T12:34:56.789Z"
}

The table-repair API

Initiates a table repair operation.

Endpoint: GET /ace/table-repair

Request Body:

{
    "cluster_name": "my_cluster",        // required
    "diff_file": "/path/to/diff.json",   // required
    "source_of_truth": "primary",        // required unless fix_nulls is true
    "table_name": "public.users",        // required
    "dbname": "mydb",                    // optional
    "dry_run": false,                    // optional, default: false
    "quiet": false,                      // optional, default: false
    "generate_report": false,            // optional, default: false
    "upsert_only": false,                // optional, default: false
    "insert_only": false,                // optional, default: false
    "bidirectional": false,              // optional, default: false
    "fix_nulls": false,                  // optional, default: false
    "fire_triggers": false               // optional, default: false
}

Parameters:

cluster_name (required): Name of the cluster
diff_file (required): Path to the diff file
source_of_truth (required): Source node for repairs
table_name (required): Fully qualified table name
dbname (optional): Database name
dry_run (optional): Simulate repairs (default: false)
quiet (optional): Suppress output (default: false)
generate_report (optional): Create detailed report (default: false)
upsert_only (optional): Skip deletions (default: false)
insert_only (optional): Repair INSERT statements only (default: false)
bidirectional (optional): Insert missing rows in a bidirectional manner (default: false)
fix_nulls (optional): Fix NULL values by comparing across nodes (default: false)
fire_triggers (optional): fire triggers when ACE performs a repair; note that ENABLE ALWAYS triggers will always fire. (default: false)

Example Request:

curl -X POST "http://localhost:5000/ace/table-repair" \
  -H "Content-Type: application/json" \
  --cert /path/to/client.crt \
  --key /path/to/client.key \
  -d '{
    "cluster_name": "my_cluster",
    "diff_file": "/path/to/diff.json",
    "source_of_truth": "primary",
    "table_name": "public.users"
  }'

Example Response:

{
    "task_id": "tr_20240315_123456",
    "submitted_at": "2024-03-15T12:34:56.789Z"
}

The table-rerun API

Reruns a previous table diff operation.

Endpoint: POST /ace/table-rerun

Request Body:

{
    "cluster_name": "my_cluster",        // required
    "diff_file": "/path/to/diff.json",   // required
    "table_name": "public.users",        // required
    "dbname": "mydb",                    // optional
    "quiet": false,                      // optional, default: false
    "behavior": "multiprocessing"        // optional, default: "multiprocessing"
}

Parameters:

cluster_name (required): Name of the cluster
diff_file (required): Path to the previous diff file
table_name (required): Fully qualified table name
dbname (optional): Database name
quiet (optional): Suppress output (default: false)
behavior (optional): Processing behavior ["multiprocessing", "hostdb"]

Example Request:

curl -X POST "http://localhost:5000/ace/table-rerun" \
  -H "Content-Type: application/json" \
  --cert /path/to/client.crt \
  --key /path/to/client.key \
  -d '{
    "cluster_name": "my_cluster",
    "diff_file": "/path/to/diff.json",
    "table_name": "public.users"
  }'

Example Response:

{
    "task_id": "tr_20240315_123456",
    "submitted_at": "2024-03-15T12:34:56.789Z"
}

The task-status API

Retrieves the status of a submitted task.

Endpoint: GET /ace/task-status/<task_id>

Parameters:

task_id (required): The ID of the task to check

Example Request:

curl "http://localhost:5000/ace/task-status?task_id=td_20240315_123456" \
  --cert /path/to/client.crt \
  --key /path/to/client.key

Example Response:

{
    "task_id": "td_20240315_123456",
    "task_type": "table-diff",
    "status": "COMPLETED",
    "started_at": "2024-03-15T12:34:56.789Z",
    "finished_at": "2024-03-15T12:35:01.234Z",
    "time_taken": 4.445,
    "result": {
        "diff_file": "/path/to/output.json",
        "total_rows": 10000,
        "mismatched_rows": 5,
        "summary": {
            // Additional task-specific details
        }
    }
}

Spock Exception Update API

Updates the status of a Spock exception.

Endpoint: POST /ace/update-spock-exception

Request Body:

{
    "cluster_name": "my_cluster",                   // required
    "node_name": "node1",                           // required
    "dbname": "mydb",                               // optional
    "exception_details": {                          // required
        "remote_origin": "origin_oid",              // required
        "remote_commit_ts": "2024-03-15T12:34:56Z", // required
        "remote_xid": "123456",                     // required
        "command_counter": 1,                       // optional
        "status": "RESOLVED",                       // required
        "resolution_details": {                     // optional
            "details": "Issue fixed"
        }
    }
}

Parameters:

cluster_name (required): Name of the cluster
node_name (required): The name of the node
dbname (optional): The name of the database
exception_details (required)
- remote_origin (optional): The OID of the origin
- remote_commit_ts (optional): The timestamp of the exception
- remote_xid (optional): The XID of the transaction
- command_counter (optional): The number of commands executed
- status (optional): The current state of the exception
- resolution_details (optional):
  - details: Include details about the exception

Example Request:

curl -X POST "http://localhost:5000/ace/update-spock-exception" \
  -H "Content-Type: application/json" \
  --cert /path/to/client.crt \
  --key /path/to/client.key \
  -d '{
    "cluster_name": "my_cluster",
    "node_name": "node1",
    "exception_details": {
        "remote_origin": "origin1",
        "remote_commit_ts": "2024-03-15T12:34:56Z",
        "remote_xid": "123456",
        "status": "RESOLVED"
    }
  }'

Example Response:

{
    "message": "Exception status updated successfully"
}

API Error Responses

ACE API endpoints return error responses in the following format:

{
    "error": "Description of what went wrong"
}

Common HTTP status codes:

200: Success
400: Bad Request (missing or invalid parameters)
401: Unauthorized (missing or invalid client certificate)
415: Unsupported Media Type (request body is not JSON)
500: Internal Server Error
